Thiết bị lưu trữ NAS Synology FS3400

215.000.000đ

- CPU: Intel Xeon E3 quad-core 3.3GHz

- RAM: 16GB DDR4 (có thể nâng cấp tối đa 128GB)

- Số lượng ổ cứng: 24 ổ 2.5"

- LAN: 2 x 10GbE RJ-45 (10GBASE-T) và 4 x Gigabit RJ-45

- Kích thước: 88 x 430.5 x 692 mm

- Cân nặng: 14.9 kg

Khuyến mãi

Gọi Hotline để nhận nhiều ưu đãi hấp dẫn !

Thiết bị lưu trữ NAS Synology FS3400

Tốc độ cực nhanh với TCO thấp hơn

Với CPU 8 nhân và bộ nhớ RDIMM 16GB ECC, FS3400 cung cấp hơn 137.000 IOPS ghi ngẫu nhiên 4K, đáp ứng nhu cầu phân tích thời gian thực, xử lý giao dịch trực tuyến và dịch vụ cơ sở dữ liệu quan trọng. 1 Với Ethernet 10GbE tích hợp, mở rộng PCIe và sự hỗ trợ của nhiều ổ đĩa SAS và SATA khác nhau, FS3400 cung cấp triển khai máy chủ flash linh hoạt và tiết kiệm theo yêu cầu.

RAID F1

Do đặc thù của công nghệ SSD và RAID, một thách thức chung nằm ở việc làm thế nào để ngăn chặn tất cả các ổ đĩa bị hỏng cùng một lúc vì khối lượng công việc phân bổ đều. RAID F1 giảm bớt vấn đề này bằng thuật toán được thiết kế đặc biệt để phân phối khối lượng công việc không đồng đều vào các ổ đĩa, tăng cường khả năng phục hồi của nhóm lưu trữ và đảm bảo dữ liệu của bạn vẫn an toàn.

Giải pháp sao lưu cuối cùng

FS3400 tích hợp các ứng dụng sao lưu khác nhau vào giao diện người dùng trực quan, cung cấp các công nghệ lưu trữ lâu bền để bảo vệ dữ liệu quý giá của bạn trên mọi thiết bị.

Active Backup for Business: Tập trung các tác vụ sao lưu cho VMware, Windows và máy chủ tệp. Khôi phục bất cứ điều gì bạn muốn nhanh chóng và đáng tin cậy khi cần thiết.

Hyper Backup: Sao lưu toàn diện dữ liệu của bạn vào thư mục dùng chung cục bộ, thiết bị bên ngoài, NAS Synology khác, máy chủ rsync hoặc đám mây công cộng để đảm bảo an toàn dữ liệu.

Synology Drive: Bảo vệ máy tính của bạn với Synology Drive Client. Dễ dàng thực hiện sao lưu dữ liệu thời gian thực và phục hồi tập tin tại thời điểm.

Active Backup for Office 365 / G Suite: Bảo vệ dữ liệu công ty được lưu trữ trên đám mây. Giải pháp sao lưu tại chỗ với bảng điều khiển tập trung. Tối ưu hóa hiệu quả lưu trữ với công nghệ chống trùng lặp đơn và cấp khối.

Giải pháp ảo hóa lưu trữ được chứng nhận đầy đủ

Synology lưu trữ iSCSI hỗ trợ đầy đủ hầu hết các giải pháp ảo hóa để nâng cao hiệu quả công việc với giao diện quản lý dễ dàng. Tích hợp VMware vSphere 6 và VAAI giúp giảm tải hoạt động lưu trữ và tối ưu hóa hiệu quả tính toán. Windows Offloaded Data Transfer (ODX) tăng tốc độ truyền dữ liệu và tốc độ di chuyển. Hỗ trợ OpenStack Cinder biến NAS Synology của bạn thành một thành phần lưu trữ dựa trên khối.

Thông tin phần cứng

CPU

Intel® Xeon® D-1541 8-core 2.1GHz, Turbo Boost up to 2.7GHz

Hardware encryption engine

Yes (AES-NI)

Memory

16 GB DDR4 ECC RDIMM (expandable up to 128 GB)

Compatible drive type

24 x 2.5" SAS SSD/HDD or SATA SSD (drives not included)

Hot swappable drive

Yes

External port

• 2 x USB 3.0 port
• 1 x Expansion port

Dimensions (HxWxD)

• 88 x 430.5 x 692 mm
• 88 x 482 x 724 mm (with server ears)

Weight

14.9 kg

LAN

• 2 x 10GbE RJ-45 (10GBASE-T)
• 4 x Gigabit RJ-45

Wake on LAN/WAN

Yes

PCIe 3.0 slot

• 1 x 8-lane x8 slot
• High-performance network interface card support

Scheduled power on/off

Yes

System fan

4 (80 x 80 x 32 mm)

AC input power voltage

100V to 240V AC

Power frequency

50/60Hz, single phase

Operating temperature

0°C to 35°C (32°F to 95°F)

Storage temperature

-20°C to 60°C (-5°F to 140°F)

Relative humidity

5% to 95% RH

Maximum operating altitude

5,000 m (16,400 ft)

Thông tin DSM

Networking protocol

SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN™ , L2TP)

File system

• Internal: Btrfs, ext4
• External: Btrfs, ext4, ext3, FAT, NTFS, HFS+, exFAT4

Supported RAID type

Basic, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, Synology RAID F1

Storage management

• Maximum single volume size: 108TB/200TB (at least 32 GB RAM required, for RAID 5 or RAID 6 groups only)
• Maximum system snapshots: 65,5365
• Maximum internal volumes: 256

SSD cache

Read/write cache support

File sharing capability

• Maximum local user accounts: 16,000
• Maximum local groups: 512
• Maximum shared folders: 512
• Maximum concurrent SMB/NFS/AFP/FTP connections: 4,000

Privilege

Windows Access Control List (ACL), application privilege

Directory service

Windows® AD integration: Domain users login via SMB/NFS/AFP/FTP/File Station, LDAP integration

Virtualization

VMware vSphere® 6.5, Microsoft Hyper-V® , Citrix®, OpenStack®

Security

Firewall, encryption shared folder, SMB encryption, FTP over SSL/TLS, SFTP, rsync over SSH, login auto block, Let's Encrypt
support, HTTPS (customizable cipher suite)

Supported client

Windows 7 onwards, Mac OS X® 10.11 onwards

Supported browser

Chrome®, Firefox®, Edge®, Internet Explorer® 10 onwards, Safari® 10 onwards; Safari (iOS 10 onwards), Chrome (Android™ 6.0
onwards) on tablets

Interface language

English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svensk, Nederlands, Русский, Polski, Magyar,
Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย,

Các gói và ứng dụng

Synology Drive

Provides a universal portal to synchronize files across various platforms, including Windows, macOS, Linux, Android and iOS.
• Maximum hosted files: 5,000,000
• Maximum concurrent connections for PC clients: 2,000

File Station

Virtual drive, remote folder, Windows ACL editor, compressing/extracting archived files, bandwidth control for specific users
or groups, creating sharing links, transfer logs

FTP Server

Bandwidth control for TCP connections, custom FTP passive port range, anonymous FTP, FTP SSL/TLS and SFTP protocol,
boot over the network with TFTP and PXE support, transfer logs

Presto File Server6

High-speed data transfer over WAN with exclusive SITA technology between Synology NAS and desktop

Cloud Sync

One or two-way synchronization with public cloud storage providers, including Alibaba Cloud OSS, Amazon Drive, Amazon
S3-compatible storage, Backblaze B2, Baidu Cloud, Box, Dropbox, Google Cloud Storage, Google Drive, hubiC, MegaDisk,
Microsoft OneDrive, OpenStack Swift-compatible storage, Tencent COS, WebDAV servers, Yandex Disk

Universal Search

Offers global searches for applications and files

iSCSI Manager

• Maximum iSCSI targets: 256
• Maximum iSCSI LUNs: 512
• Supports iSCSI LUN clone/snapshot

Virtual Machine Manager

Multiple virtual machines deployable, including Windows, Linux, or Virtual DSM

Hyper Backup

Supports local backup, network backup, and backup data to public clouds

Backup tools

DSM configuration backup, macOS Time Machine support, Synology Drive Client desktop application
Shared folder sync - maximum task numbers: 32

Snapshot Replication

• Maximum shared folder snapshots: 1,024
• Maximum replications: 64

Synology High Availability

Reduces service downtime by setting up two identical NAS into one high-availability cluster

Active Backup for G Suite

Supports G Suite My Drive and Team Drive backup and restoration

Active Backup for Office 365

Supports Office 365 OneDrive for Business, mail, contacts, and calendar backup and restoration

Active Backup for Business

All-in-one backup solution designed for heterogeneous business IT environments that enables IT admins to remotely manage
and monitor protection over PC, servers, and VM on one centralized console

Collaboration tools

Supports collaboration with instant message service Synology Chat, online editor Synology Office, and scheduling assistant
Synology Calendar
• Maximum Chat users: 6,000
• Maximum Office users: 3,400
• Calender: Supports CalDAV and access via mobile devices

Note Station

Rich-text note organization and versioning, encryption, sharing, media embedding and attachments

Synology MailPlus Server

Secure, reliable, and private mail solution with high-availability, load balancing, security and filtering design (Including 5 free
email account licenses. Additional accounts require the purchasing of additional licenses)

Synology MailPlus

Intuitive webmail interface for MailPlus Server, customizable mail labels, filters, and user interface

Surveillance Station

Maximum IP cameras: 100 (total of 3,000 FPS at 720p, H.264) (Including two free camera licenses. Additional cameras require
the purchasing of additional licenses)

Synology Directory Server

Provides a flexible and cost-effective domain controller solution

Central Management System

Provides a single interface to manage and monitor multiple Synology NAS models

VPN Server

Maximum connections: 40, supported VPN protocol: PPTP, OpenVPN™, L2TP/IPSec

Mail Server

Supported Mail Server Protocols: POP3, SMTP, IMAP, Support LDAP/AD account

Mail Station

Webmail interface for Mail Server to receive emails from multiple POP3 mailboxes, customizable SMTP server

Web Station

Virtual host (up to 30 websites), PHP/MariaDB®, third-party applications support

Other packages

DNS Server, RADIUS Server, Log Center

Storage Analyzer

Volume and quota usage, total size of files, volume usage and trends based on past usage, size of shared folders, large files,
most recently modified files, least recently accessed files

Antivirus Essential

Full system scan, scheduled scan, white list customization, virus definition auto update

Security Advisor

Malware detection/removal, user account/password, network, system-related security scan

Other packages

Additional 3rd-party packages available in Package Center
